z-conference

Z Installation

La serie Z Conference e la serie Z Entertainment utilizzano la famosa tecnologia Omniray sono il perfetto connubio tra l’elevata qualità del suono Hi-End applicato ad un prodotto Pro
Applicazioni: conference hall, sale meeting, chiese, alberghi, spa, palestre, musei, gallerie d’arte, fiere
Richiedi Informazioni

La Serie Conference

Scarica il Catalogo

ZC 42A

Dispersion 120°V – 120°H
System Type Bass Reflex
Transducers LF 2 X 4” (1’’ V.C.) | HF 1 x 2,5’’ (0,8” V.C.)
Impedance 8Ω - 16Ω on request
Rated Power 140W (AES)
Peak Power 560W
Sensitivity 1W/1m 90 dB
SPL cont/peak 1m 113 dB Spl
Freq. range (+/-3dB) 120Hz – 18kHz
Dimension (mm) W 115 x H 400 x D 140
Weight (kg) 3,2

Preset

Datasheet

Users Guide

ZC 44A

Dispersion 120°V – 120°H
Transducers LF 4 x 4” (1’’ V.C.) | HF 1 x 2,5’’ (0,8” V.C.)
Impedance 8Ω
Rated Power 280W (AES)
Peak Power 1120W
Sensitivity 1W/1m 90 dB
SPL cont/peak 1m 115 dB Spl
Freq. range (+/-3dB) 120Hz – 18kHz
Dimension (mm) W 115 x H 600 x D 140
Weight (kg) 4,8

Preset

Datasheet

Users Guide

ZC 51A

Dispersion 120°V – 120°H
System Type Bass Reflex
Transducers LF 1 X 5’’ (1,5’’ V.C.) | HF 1 x 2,5’’ (0,8” V.C.)’
Impedance 8Ω
Rated Power 70W (AES)
Peak Power 280W
Sensitivity 1W/1m 91 dB
SPL cont/peak 1m 110 dB Spl
Freq. range (+/-3dB) 90Hz – 18kHz
Dimension (mm) H 300 x W 150 x D 174
Weight (kg) 3,3

DWG

Datasheet

Users Guide

ZC 61A

Dispersion 120°V – 120°H
System Type Bass Reflex
Transducers LF 1 X 6’’ (1,5’’ V.C.) | HF 1 x 2,5’’ (0,8” V.C.)
’ Impedance 8Ω
Rated Power 100W (AES)
Peak Power 400W
Sensitivity 1W/1m 91,5 dB
SPL cont/peak 1m 113 dB Spl
Freq. range (+/-3dB) 70Hz – 18kHz
Dimension (mm) H 360 x W 180 x D 209
Weight (kg) 5

DWG

Datasheet

Users Guide

ZC 81A

Dispersion 120°V – 120°H
System Type Bass Reflex
Transducers LF 1 X 8’’ (2’’ V.C.) | HF 1 x 2,5’’ (0,8” V.C.)’
Impedance 8Ω
Rated Power 150W (AES)
Peak Power 600W
Sensitivity 1W/1m 93 dB
SPL cont/peak 1m 117 dB Spl
Freq. range (+/-3dB) 55Hz – 18kHz
Dimension (mm) H 440 x W 220 x D 255
Weight (kg) 7

DWG

Datasheet

Users Guide

La Serie Entertainment

Scarica il Catalogo

ZE 201A

Dispersion 120°V – 120°H
Transducers LF 1 X 2’’ (0,8’’ V.C.)
Impedance 8Ω - 16Ω on request
Rated Power 20W (AES)
Peak Power 80W
Sensitivity 1W/1m 85 dB
SPL cont/peak 1m 98 dB Spl
Freq. range (+/-3dB) 350Hz – 18kHz
Dimension (mm) H 80 x W 75 x D 89
Weight (kg) 0,3

Preset

Datasheet

Users Guide

ZE 251A

Dispersion 120°V – 120°H
Transducers LF 1 X 2’’ (0,8’’ V.C.)’
Impedance 8Ω - 16Ω on request
Rated Power 20W (AES)
Peak Power 80W
Sensitivity 1W/1m 85 dB
SPL cont/peak 1m 98 dB Spl
Freq. range (+/-3dB) 350Hz – 18kHz
Dimension (mm) H 100 x W 75 x D 89
Weight (kg) 0,4

DWG

Datasheet

Users Guide

ZE 201ACX

Dispersion 120°V – 120°H
Transducers LF 1 X 2’’ (0,8’’ V.C.)
Impedance 8Ω - 16Ω on request
Rated Power 20W (AES)
Peak Power 80W
Sensitivity 1W/1m 85 dB
SPL cont/peak 1m 98 dB Spl
Freq. range (+/-3dB) 350Hz – 18kHz
Crossover Freq. 350Hz 12dB/Oct
Dimension (mm) H 80 x W 75 x D 89
Weight (kg) 0,32

Datasheet

Users Guide

ZE 251ACX

Dispersion 120°V – 120°H
Transducers LF 1 X 2’’ (0,8’’ V.C.)’
Impedance 8Ω - 16Ω on request
Rated Power 20W (AES)
Peak Power 80W
Sensitivity 1W/1m 85 dB
SPL cont/peak 1m 98 dB Spl
Freq. range (+/-3dB) 350Hz – 18kHz
Crossover Freq. 300Hz 12dB/Oct.
Dimension (mm) H 100 x W 75 x D 89
Weight (kg) 0,42

Datasheet

Users Guide

ZE 252A

Dispersion 120°V – 120°H
Transducers LF 2 X 2,5’’ (0,8’’ V.C.) | HF 1 x 2,5” (0,8” V.C.)
Impedance 8Ω - 16Ω on request
Rated Power 20W (AES) – 20W – 100 V (ZE 252AT)
Peak Power 80W
Sensitivity 1W/1m 85 dB
SPL cont/peak 1m 98 dB Spl
Freq. range (+/-3dB) 350Hz – 18kHz
Dimension (mm) H 300 x W 75 x D 88
Weight (kg) 1,2 – 1,7 ( ZE 252AT )

DWG

Datasheet

Users Guide

ZE 254A

Dispersion 120°V – 120°H
Transducers LF 4 X 2,5’’ (0,8’’ V.C.) | HF 1 x 2,5”” (0,8” V.C.)’
Impedance 8Ω
Rated Power 80W (AES)
Peak Power 320W
Sensitivity 1W/1m 87 dB
SPL cont/peak 1m 105 dB Spl
Freq. range (-6dB) 150Hz – 18kHz
Dimension (mm) H 500 x W 75 x D 88
Weight (kg) 1,9

DWG

Datasheet

Users Guide

ZE 259A

Dispersion 120°V – 120°H
Transducers LF 9 X 2,5’’ (0,8’’ V.C.) | HF 2 x 2,5” (0,8” V.C.)
Impedance 8Ω
Rated Power 180W (AES)
Peak Power 720W
Sensitivity 1W/1m 87 dB
SPL cont/peak 1m 110 dB Spl
Freq. range (+/-3dB) 200Hz – 18kHz
Dimension (mm) H 1000 x W 75 x D 89
Weight (kg) 4

DWG

Datasheet

Users Guide

ZE 41A

Dispersion 120°V – 120°H
System Type Bass Reflex
Transducers LF 1 X 4’’ (1’’ V.C.)
Impedance 8Ω - 16Ω on request
Rated Power 70W (AES) – 20 W – 100 V (ZE 41AT )
Peak Power 280W
Sensitivity 1W/1m 90 dB
SPL cont/peak 1m 109 dB Spl
Freq. range (+/-3dB) 140Hz – 16kHz
Dimension (mm) H 130 x W 115 x D 160
Weight (kg) 1 – 1,5 ( ZE 41AT )

DWG

Datasheet

Users Guide

ZE 41AP

Dispersion 120°V – 120°H
System Type Bass Reflex
Transducers LF 1 X 4’’ (1’’ V.C.)
Impedance 8Ω - 16Ω on request
Rated Power 70W (AES) – 20 W – 100 V (ZE 41APT)
Peak Power 280W
Sensitivity 1W/1m 90 dB
SPL cont/peak 1m 109 dB Spl
Freq. range (+/-3dB) 140Hz – 16kHz
Dimension (mm) H 190 x W 190 x D 122
Weight (kg) 1,2 – 1,6 ( ZE 41APT )

DWG

Datasheet

Users Guide

ZE 108A

Dispersion OMNI
Transducers 1 x 8’’ (2’’ V.C.)
Impedance 8Ω ( 16Ω on Request )
Rated Power 150W (AES)
Peak Power 600W
Sensitivity 1W/1m 93 dB
SPL cont/peak 1m 112 dB
Freq. range (+/-3dB) 35Hz-250Hz
Dimension (mm) H 300 x W 270 x D 230
Weight (kg) 6,4

Preset

Datasheet

Users Guide

ZE 108ACX

Dispersion OMNI
Transducers 1 x 8’’ (2’’ V.C.)
Impedance 8Ω ( 16Ω on Request )
Rated Power 150W (AES)
Peak Power 600W
Sensitivity 1W/1m 93 dB
SPL cont/peak 1m 112 dB
Freq. range (+/-3dB) 35Hz-250Hz
Dimension (mm) H 300 x W 270 x D 230
Weight (kg) 6,5

Datasheet

Users Guide

ZE 205A

Dispersion OMNI
Transducers 2 x 5’’ (1’’ V.C.)
Impedance 16Ω
Rated Power 150W (AES)
Peak Power 600W
Sensitivity 1W/1m 90 dB
SPL cont/peak 1m 112 dB
Freq. range (+/-3dB) 75Hz-300Hz
Dimension (mm) H 200 x W 360 x D 200
Weight (kg) 5

DWG

Datasheet

Users Guide

ZE 205ACX

Dispersion OMNI
Transducers 2 x 5’’ (1’’ V.C.)
Impedance 16Ω
Rated Power 150W (AES)
Peak Power 600W
Sensitivity 1W/1m 90 dB
SPL cont/peak 1m 112 dB
Freq. range (+/-3dB) 75Hz-300Hz
Crossover Freq. 200Hz 12dB/Oct.
Dimension (mm) H 200 x W 360 x D 200
Weight (kg) 5,1

Datasheet

Users Guide

ZE 206A

Dispersion OMNI
Transducers 2 x 6’’ (1,5’’ V.C.)
Impedance 8Ω
Rated Power 200W (AES)
Peak Power 800W
Sensitivity 1W/1m 91,5 dB
SPL cont/peak 1m 113 dB
Freq. range (+/-3dB) 65Hz-300Hz
Dimension (mm) H 250 x W 450 x D 180
Weight (kg) 7

DWG

Datasheet

Users Guide

ZE 206ACX

Dispersion OMNI
Transducers 2 x 6’’ (1,5’’ V.C.)
Impedance 8Ω
Rated Power 200W (AES)
Peak Power 800W
Sensitivity 1W/1m 91,5 dB
SPL cont/peak 1m 113 dB
Freq. range (+/-3dB) 65Hz-300Hz
Dimension (mm) H 250 x W 450 x D 180
Weight (kg) 7,2

Datasheet

Users Guide

ZE 208A

Dispersion OMNI
Transducers 2 x 8’’ (2’’ V.C.)
Impedance 8Ω
Rated Power 300W (AES)
Peak Power 1200W
Sensitivity 1W/1m 93 dB
SPL cont/peak 1m 117 dB
Freq. range (+/-3dB) 50Hz-250Hz
Dimension (mm) H 300 x W 540 x D 220
Weight (kg) 9

DWG

Datasheet

Users Guide

La Serie SR

Scarica il Catalogo

Z SR

Dispersion OMNI
Transducers LF 4 x 4’’ (1’’ V.C.) | HF 1 x Soft Dome Tweeter 19 mm
Omniray GZ4
Impedance 8Ω
Rated Power 150W (AES)
Peak Power 300W
Sensitivity 1W/1m 92 dB Spl
SPL cont/peak 1m 116 dB Spl
Freq. range (-6dB) 120Hz-20KHz
Dimension (mm) H 270 x W 270 x D 125
Weight (kg) 3,5

Z SRC

Dispersion OMNI
Transducers LF 4 x 4’’ (1’’ V.C.) | HF 1 x Soft Dome Tweeter 19 mm
Omniray GZ4
Impedance 8Ω
Rated Power 150W (AES)
Peak Power 300W
Sensitivity 1W/1m 92 dB Spl
SPL cont/peak 1m 116 dB Spl
Freq. range (-6dB) 120Hz-20KHz
Dimension (mm) H 270 x W 270 x D 125
Weight (kg) 3,5
